#8-15 x 1 Inch Zinc Plated Low Carbon Steel Square Drive Flat - Countersunk Head Type-A Self-Tapping Sheet Metal Screw

Item B13.08.1

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

These machine screws have deeply sunk heads with flat top surfaces for fastening flatly against sides of metal joints and equipment. These screws sit flush against the surface of panels and electrical components for a finished look.

  • Origin: Imported
  • Drive Size: #2S
  • Drive Type: Square
  • Finish: Zinc
  • Head Diameter: 0.282 - 0.312 Inch
  • Head Height: 0.072 Inch
  • Head Style: Flat - Countersunk
  • Industry Standard: ASME/ANSI B18.6.4 SAE J78
  • Item: Self-Tapping Sheet Metal Screw
  • Length: 1 Inch
  • Material: Low Carbon Steel
  • Measurement: Inch
  • Origin: Imported
  • Point Type: Type-A
  • Recess Across Flat: 0.112 Inch
  • Recess Penetration Gagging Depth: 0.048 - 0.063 Inch
  • Specification: ASME/ANSI B18.6.4 SAE J78 SAE J933
  • Threads Per Inch: 15

Photographs are representational and may not be size accurate.

Key Specifications
Diameter #8
Drive Type Square
Finish Zinc
Head Style Flat
Length 1 Inch
Material Alloy Steel
Measurement Inch
Origin IMPORT
Point Type Type A
