100R16 Industrial / Agricultural 2-Wire Braided High Pressure Hydraulic Hose 1 Inch - Sold Per Foot

Item J97.017.16.1

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

1" SAE 100R16 Hydraulic Hose is recommended for hydraulic system service with petroleum and water-base fluids or general industrial service. Hose Features Include Oil-resistant Synthetic Rubber Inner Tubing Reinforced 2-Wire braid of high tensile steel wire. Oil and Abrasion-Resistant synthetic rubber outer cover protection. Same working pressure & Half the bend radius of SAE 100R2. Interchanges with Aeroquip GH781-16 Gates 16M2T Parker 431-16 and Weatherhead H24516

  • SAE 100R16 TWO WIRE HI-PRESSURE EXTREMELY FLEXIBLE HYDRAULIC HOSE
  • Applications: High Pressure Hydraulics Industrial or Agricultural
  • Cover: Abrasion and Flame Resistant Cover MSHA Approved
  • Reinforcement: Two-Wire Braids
  • Temperature: -40F to +212F (-40C to +100C)
  • Couplings Series: Vari-Crimp (3/4" - 1") A-Series Grip-Crimp
  • Inside Diameter - 1"
  • Outside Diameter - 1.405"
  • Maximum Working Pressure - 2 000 PSI
  • Minimum Burst Pressure - 8 000 PSI
  • Minimum Bend Radius - 6"
  • **Crimps to 100R1AT One Wire Thin Cover Specifications - Tighter Bend Radius than R1 and R2**

Photographs are representational and may not be size accurate.

Key Specifications
Inside Diameter 1.00 Inch
