FastServ

100R16/2Sc Industrial / Agricultural 2-Wire Braided High Pressure Hydraulic Hose 1/4 Inch- Sold Per Foot

Item J97.016.4.1

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

100R16/2SC Hydraulic Hose is recommended for hydraulic system service with petroleum and water-base fluids or general industrial service. Hose Features Include Oil-resistant Synthetic Rubber Inner Tubing Reinforced 2-Wire braid of high tensile steel wire. Oil and Abrasion-Resistant synthetic rubber outer cover protection. Same working pressure & Half the bend radius of SAE 100R2. Interchanges with Aeroquip GH781-10 Gates 10M2T Parker 431-10 and Weatherhead H24510

  • Spec: SAE 100R16 / DIN 2SC MSHA
  • Applications: High Pressure Hydraulics Industrial or Agricultural
  • Cover: Abrasion and Flame Resistant Cover MSHA approved
  • Reinforcement: Two Wire Braids
  • Temperature: -40F to +212F (-40C to +100C)Coupling Series: Vari-Crimp (1/4”-5/8”) A-Series Grip-Crimp
  • Inside Diameter - 1/4"
  • Outside Diameter - 0.530"
  • Maximum Working Pressure - 5 800 PSI
  • Minimum Burst Pressure - 23 200 PSI
  • Minimum Bend Radius - 2"
  • **Crimps to 100R1AT One Wire Thin Cover Specifications - Tighter Bend Radius than R1 and R2**

Photographs are representational and may not be size accurate.

Key Specifications
Inside Diameter 1/4 Inch
